Goal Zero Nomad 400 PRO Solar Bundles

NOMAD 400 Solar Panel Highlights

• POWERFUL
  This portable panel provides 400 Watts of solar so you can recharge your power station faster.

• PORTABLE
  The Nomad 400 is designed to be easy to take with you, whether you’re overlanding, camping, or setting up in the backyard during a power outage. It’s lightweight and folds down to be more compact—plus it includes a shoulder strap and carrying handles.

• EFFICIENT
  The Nomad 400 has an industry-leading efficiency rating for optimal energy collection, conversion, and retention.

Tips & Tricks for using solar panels

• The solar panel does not hold a charge - it produces power when it is exposed to sunlight.

• Place solar panels towards the sun at an angle.

• Connect High Power Power to Yeti Power Station.

• Adjust solar panel as the sun moves across the sky.

CHARGE TIMES

(8) Nomad Solar Panel Bundle

• Yeti PRYeti PRO 4000: 1.5 - 3 Hours

• Yeti PRO 8000: 3 - 6 Hours

• Compatible with Yeti PRO 4000. This bundle is not compatible with the Yeti X line due to voltage restrictions.

(4) Nomad Solar Panel Bundle

• Yeti PRO 4000: 3 - 6 Hours

• Yeti PRO 8000: 6 - 12 Hours

• Compatible with Yeti PRO 4000. This bundle is not compatible with the Yeti X line due to voltage restrictions.

(2) Nomad Solar Panel Bundle

• Yeti PRO 4000: 6 - 12 Hours

• Yeti PRO 8000: 12 - 24 Hours

• Compatible with Yeti PRO 4000. This bundle is not compatible with the Yeti X line due to voltage restrictions.

GENERAL

• KIT SKUs:

  • 44585 SKU: (8) Nomad 400 Solar Panels

  • 44584 SKU: (4) Nomad 400 Solar Panels

  • 44583 SKU: (2) Nomad 400 Solar Panels

• Product SKU: 11950

• Weight:  36.60 lbs. (16.6 kg) per Nomad 400 Solar Panel

• Dimensions (Folded): 28.54 x 31.69 x 1.18 in. (72.5 x 80.5 x 3 cm)

• Dimensions (Unfolded): 113.98 x 31.69 x 0.2 in. (289.5 x 80.5 x 0.5 cm)

• Panel Construction: Lamination

• Ingress Protection: IP65

• Warranty: 2 Year

• Operating Temperature Range: -40-185 °F (-40-85 °C)

• Maximum System Voltage: 1000 V

PORTS

• Output Port (HPP): 14-150V, 40 A, 400W

• Cable Length: 35.43 in (0.9 m)

• Guage: 12 AWG

• 15 ft HPP Extention (Included): 15 ft, 12 AWG

• Output Port (USB-A): 5 V, 2.4 A, 12 W, 7.87 in (0.2 m) 12 AWG

SOLAR

• Rated Power: 400 Watts

• Peak Power Operating Voltage (Vmp): 20.66 V

• Peak Power Operating Current (Imp): 20.45 A

• Cell Type: Monocrystalline

• Open Circuit Voltage (Voc): 23.84 V

• Short Circuit Current (Isc): 20.45 A

• Series Fuse Rating: 15 A

• Temperature Coefficient (Voltage): -0.30%/°C

• Temperature Coefficient (Current): -0.44%/°C

• Temperature Coefficient (Power): -0.44%/°C

What’s in the Box?

(8) Nomad Solar Panel Bundle

• (8) Nomad 400 Solar Panels

• (8) 15 ft HPP Extension Cable

• (2) 4 x HPP to 1x HPP+ Solar Series Combiner

• (1) 3x HPP+ Solar Parallel Combiner

• Shoulder Straps

• 32X Ground Stakes

(4) Nomad Solar Panel Bundle

• (4) Nomad 400 Solar Panels

• (4) 15 ft HPP Extension Cable

• 4 x HPP to 1x HPP+ Solar Series Combiner

• Shoulder Straps

• 16X Ground Stakes

(2) Nomad Solar Panel Bundle

• (2) Nomad 400 Solar Panels

• (2) 15 ft HPP Extension Cable

• (1) 15 ft HPP+ Extension Cable

• 4 x HPP to 1x HPP+ Solar Series Combiner

• Shoulder Straps

• 8X Ground Stakes
